MBM Phrike – 20" Fat Tyre Urban Bike

The MBM Phrike 20" Fat Tyre Urban Bike is a powerhouse e-bike designed for riders who want extra grip, stability, and standout style on city streets. Powered by a 250W Etrotek rear hub motor (48V) delivering an impressive 50 Nm of torque, it offers smooth, strong pedal assistance up to the UK-legal 25 km/h (15.5 mph), perfect for conquering urban routes and light trails alike.

Its Ant Power 48V, 17.5 Ah (840 Wh) battery delivers exceptional range and performance, supporting your long commutes or adventurous rides with confidence. Built on a one-size 417 mm frame and weighing 26.5 kg, the Phrike combines rugged looks with comfort, control, and durability.

User Manual

• Fat 20" tyres offer superior grip, stability, and a bold urban look

• High-torque Etrotek motor (50 Nm) powers through city hills and flats

• Massive 840 Wh battery supports extended rides without worry

• Smooth Shimano 7-speed shifting for versatile performance

• Front suspension fork for added comfort on uneven surfaces

• Hydraulic disc brakes deliver precise, confident stopping power

• Motor: Etrotek rear hub, 250W, 50 Nm torque, 48V

• Top Speed: 25 km/h (15.5 mph) legal, higher when unrestricted

• Battery: Ant Power 48V, 17.5 Ah (840 Wh), removable

• Gearing: Shimano M315, 7-speed

• Rear Derailleur: Shimano Acera

• Brakes: Shimano MT200 hydraulic disc

• Discs: Shimano RT26, 160 mm front/rear

• Wheels: 20" fat alloy double-wall rims

• Tyres: 20 x 4.0 urban

• Frame: MBM Alloy 6061 hydroformed plus

• Fork: MBM suspension fork, stanchions Ø32

• Weight: 26.5 kg

• Frame Size: One size – 417 mm

• Crank Set: 170 x 46T black alloy

• Freewheel: Shimano TZ 500 14/34, 7-speed

• Saddle: MBM comfort

• Lights: Front e-bike light, 70 lux (with on/off button)

• Display: LCD

• Power Levels: 5 assist modes

Order Confirmation: Once you place your order, we will pre-authorise your card, but your payment will not be processed immediately. We will then proceed to process your payment and begin preparing your order for dispatch.
Order Delivery: All orders are typically dispatched within 5 working days of payment being processed. You will receive tracking details by email within 24 hours of dispatch. If you have not received tracking information within 6 working days of placing your order, please contact us at support@pedalgo.co.uk and we’ll assist you.
Damages on Delivery: All products are fully insured during delivery. Please inspect all items carefully at the time of delivery. If you notice any visible damage, we strongly advise that you do not accept the delivery. If you later discover damage, please email clear photos of the affected items to support@pedalgo.co.uk as soon as possible. We will initiate an insurance claim on your behalf and help arrange a replacement or refund where applicable.
Cancellations & Refunds: Orders cancelled after 48 hours may be subject to a cancellation fee. If your order has already been dispatched, you (the buyer) will be responsible for any return shipping costs. Refunds will only be issued to the original payment method used to place the order.

All MBM electric bicycles come with a 2 year warranty from the date of purchase, covering the frame, motor, and battery. To activate the warranty, the product must be registered within 15 days of purchase through the official MBM warranty portal.

Battery Coverage Details
0 to 6 months: 100 percent coverage
7 to 12 months: 50 percent coverage
13 to 24 months: 25 percent coverage

Please note: battery coverage depends on proper use and maintenance. Allowing the battery to discharge below the allowed limit may void the warranty.

Exclusions
The warranty does not cover
Normal wear and tear items such as tires, brake pads, chains, and cables
Damage from accidents, misuse, or unauthorized modifications
Improper assembly or use of incompatible parts

If you experience any issues or need support, Pedal Go is your first point of contact. We are here to help and assist you with any warranty or product concerns.

MBM Electric Bike Warranty

All MBM electric bikes come with a comprehensive manufacturer’s warranty for your peace of mind.

Warranty Coverage:

• Frame: 2 years

• Electric Motor: 2 years

• Battery: 2 years (subject to proper use and charging cycles)

• Controller & Display: 1 year

• Charger: 1 year

• Other Electrical Components: 1 year

• Mechanical Parts (gears, brakes, chain, etc.): 6 months (excluding wear and tear)

What’s Not Covered:

• Normal wear and tear (tyres, brake pads, cables, etc.)

• Damage due to misuse, accidents, neglect, or improper maintenance

• Modifications or alterations to the bike’s original condition

• Water damage caused by submersion or pressure washing

• Use of non-original parts or chargers

Warranty Claims:

To make a warranty claim, please contact us with your order number, a description of the issue, and clear photos or videos if possible. We’ll work with MBM to assess and resolve the problem quickly.

Please Note:
Regular servicing and correct use are essential to maintain warranty coverage. Batteries should be stored in a cool, dry place and charged at least once a month if not in regular use.
